Compile and install Digikam on Ubuntu 20.04 Focal

Friday, March 26, 2021

Digikam is an incredibly powerful media management tool that integrates a great collection of powerful media processing projects into a single, fairly nice and moderately intuitive user interface. The problem is that it make use of SO many projects and libraries that installation is quite fragile and most distributions are many years out of date – that is a typical sudo apt install digikam will yield version 4.5 while release is (as of this writing) 7.2.

In particular, this newer version has face detection that runs LOCALLY – not on Google or Facebook’s servers – meaning you don’t have to trade your personal photos and all the data implicit in them to a data broker to make use of such a useful tool.  Sure, Google once bought and then improved Picasa Desktop which gave you this function, but then they realized this was cutting into their data harvesting business and discontinued Picasa and tried to convince people to let them look at all their pictures with Google Photos.  We really, really need to make personal data a toxic asset, such an intolerable liability that any company that holds any personal data has negative value.  But until then, use FOSS software on your own hardware where ever possible.

You can compile the latest version on Ubuntu 20.04 Focal Fossa, though not exactly painlessly, or you can install the flatpak easily. I hate flatpaks with a passion, so I went through the exercise and found what appears to be stable success with the following procedure which yielded a fully featured digikam with zero dependency errors or warnings and all features enabled using MariaDB as a backend.

Install and configure MariaDB

sudo apt update
sudo apt install mariadb-server
sudo mysql_secure_installation

The secure options are all good, accept them unless you know better.

Start the server (if it isn’t)

sudo systemctl start mariadb.service
sudo systemctl enable mariadb --now
sudo systemctl status mariadb.service

Do some really basic config:

sudo nano /etc/mysql/mariadb.conf.d/50-server.cnf

and set:

character-set-server = utf8mb4
collation-server = utf8mb4_general_ci
default_storage_engine = InnoDB

Switch to mariadb and create an admin user account and (I’d suggest) one for digikam.  It seems this has to be done before the first connect and can’t be fixed after.  You’ll probably want to use a different ‘user’ than I did, but feel free.

sudo mariadb
CREATE USER 'gessel'@'localhost' IDENTIFIED BY 'password';
GRANT ALL ON *.* TO 'gessel'@'localhost' IDENTIFIED BY 'password';
GRANT ALL PRIVILEGES ON digikam.* TO 'gessel'@'localhost';

should correctly create the correct user – though check the instructions tab on the database connection options pane for any changes if you’re following these instructions for install of a later version. You will need the socket location to connect to the database so before exit; run:

mysqladmin -u admin -p version

Should yield something like:

Enter password:
mysqladmin  Ver 9.1 Distrib 10.3.25-MariaDB, for debian-linux-gnu on x86_64
Copyright (c) 2000, 2018, Oracle, MariaDB Corporation Ab and others.

Server version		10.3.25-MariaDB-0ubuntu0.20.04.1
Protocol version	10
Connection		Localhost via UNIX socket
UNIX socket		/var/run/mysqld/mysqld.sock
Uptime:			5 hours 26 min 6 sec

Threads: 29  Questions: 6322899  Slow queries: 0  Opens: 108  Flush tables: 1  Open tables: 74  Queries per second avg: 323.157

And note the value for UNIX socket, you’re going to need that later: /var/run/mysqld/mysqld.sock – yours might vary.

Install digiKam Dependencies

Digikam has just a few dependencies.just a few... the below command should install the needed for 7.20 on Ubuntu 20.04. Any other version combination might be different.:

sudo aptitude install \
bison \
checkinstall \
devscripts \
doxygen \
extra-cmake-modules \
ffmpeg \
ffmpegthumbnailer \
flex \
graphviz \
help2man \
jasper \
libavcodec-dev \
libavdevice-dev \
libavfilter-dev \
libavformat-dev \
libavutil-dev \
libboost-dev \
libboost-graph-dev \
libeigen3-dev \
libexiv2-dev \
libgphoto2-dev \
libjasper-dev \
libjasper-runtime \
libjasper4 \
libjpeg-dev \
libkf5akonadicontact-dev \
libkf5calendarcore-dev \
libkf5contacts-dev \
libkf5doctools-dev \
libkf5filemetadata-dev \
libkf5kipi-dev \
libkf5notifications-dev \
libkf5notifyconfig-dev \
libkf5sane-dev \
libkf5solid-dev \
libkf5threadweaver-dev \
libkf5xmlgui-dev \
liblcms2-dev \
liblensfun-dev \
liblqr-1-0-dev \
libmagick++-6.q16-dev \
libmagick++-6.q16hdri-dev \
libmagickcore-dev \
libmarble-dev \
libqt5opengl5-dev \
libqt5sql5-mysql \
libqt5svg5-dev \
libqt5webkit5-dev \
libqt5webview5 \
libqt5webview5-dev \
libqt5x11extras5-dev \
libqt5xmlpatterns5-dev \
libqtav-dev \
libqtwebkit-dev \
libswscale-dev \
libtiff-dev \
libusb-1.0-0-dev \
libx264-160 \
libx264-dev \
libx265-192 \
libx265-dev \
libxml2-dev \
libxslt1-dev \
marble \
pkg-kde-tools \
qtbase5-dev \
qtbase5-dev-tools \
qtmultimedia5-dev \
qtwebengine5-dev \

Compile Digikam

Switch to your projects directory (~/projects, say) and get the source tarball and cross your fingers and go to town. The make -j4 command will take a while to compile everything.

tar -xvf digikam-7.2.0.tar.xz
cd digikam-7.2.0.tar.xz
mkdir build
cd build
make -j4
make install/fast

the ./bootstrap.linux result should be as below – if it indicates a something is missing, then double check dependencies.  If you’ve never compiled anything before, you might need to install cmake and and some other basics:

-- ----------------------------------------------------------------------------------
--  digiKam 7.2.0 dependencies results   <>
--  MySQL Database Support will be compiled.. YES (optional)
--  MySQL Internal Support will be compiled.. YES (optional)
--  DBUS Support will be compiled............ YES (optional)
--  App. Style Support will be compiled...... YES (optional)
--  QWebEngine Support will be compiled...... YES (optional)
--  libboostgraph found...................... YES
--  libexiv2 found........................... YES
--  libexpat found........................... YES
--  libjpeg found............................ YES
--  libkde found............................. YES
--  liblcms found............................ YES
--  libopencv found.......................... YES
--  libpng found............................. YES
--  libpthread found......................... YES
--  libqt found.............................. YES
--  libtiff found............................ YES
--  bison found.............................. YES (optional)
--  doxygen found............................ YES (optional)
--  ccache found............................. YES (optional)
--  flex found............................... YES (optional)
--  libakonadicontact found.................. YES (optional)
--  libmagick++ found........................ YES (optional)
--  libeigen3 found.......................... YES (optional)
--  libgphoto2 found......................... YES (optional)
--  libjasper found.......................... YES (optional)
--  libkcalendarcore found................... YES (optional)
--  libkfilemetadata found................... YES (optional)
--  libkiconthemes found..................... YES (optional)
--  libkio found............................. YES (optional)
--  libknotifications found.................. YES (optional)
--  libknotifyconfig found................... YES (optional)
--  libksane found........................... YES (optional)
--  liblensfun found......................... YES (optional)
--  liblqr-1 found........................... YES (optional)
--  libmarble found.......................... YES (optional)
--  libqtav found............................ YES (optional)
--  libthreadweaver found.................... YES (optional)
--  libxml2 found............................ YES (optional)
--  libxslt found............................ YES (optional)
--  libx265 found............................ YES (optional)
--  OpenGL found............................. YES (optional)
--  libqtxmlpatterns found................... YES (optional)
--  digiKam can be compiled.................. YES
-- ----------------------------------------------------------------------------------

Launch and configure Digikam

The Configuration options are pretty basic, but note that to configure the Digikam back end you’ll need to use that MariaDB socket value you got before and the user you created like so UNIX_SOCKET=/var/run/mysqld/mysqld.sock:


On the first run, it will download about 350mb of code for the face recognition engine.  Hey – maybe a bit heavy, but you’re not giving the Google or Apple free lookie looks at all your personal pictures.  Also, if all this is a bit much (and, Frankly, it is) I’d consider Digikam one of the few applications that makes the whole flatpak thing seem somewhat justified.  Maybe.

Some advice on tuning:

I recommend mysqltuner highly, then maybe check this out (or just leave it default, default works well).

Tuning a database is application and computer specific, there’s no one size fits any, certainly not all, and it may change as your database grows. There are far more expert and complete tuning guides available, but here’s what I do:

Pre-Tuning Data Collection

Tuning at the most basic involves instrumenting the database to log problems, running it for a while, then parsing the performance logs for useful hints. The script is far more expert at than I’ll ever be, so I pretty much just trust it. You have to modify your mysqld.cnf file to enable performance data collection (which, BTW, slows down operation, so undo this later) which for MariaDB means adding a few lines:

sudo nano /etc/mysql/mariadb.conf.d/50-server.cnf
# enable performance schema to allow optimization, but ironically hit performance, so disable after tuning.
# in the [mysqld] section insert

Follow the instructions for installing at

I rather like this guide’s helpful instructions for putting the script in /usr/local/sbin/ so it is in the execution path:

sudo wget -O /usr/local/sbin/
sudo chmod 700 /usr/local/sbin/

Then restart with sudo service mariadb restart then go about your business with digikam – make sure you rack up some real hours to gather useful data on your performance. Things like ingesting a large collection should generate useful data. I’d suggest doing disk tuning first because that’s hardware not load dependent.

Disk tuning

Databases tend to hammer storage and SSDs, especially SLC/enterprise SSDs, massively improve DB performance over spinning disks – unless you have a massive array of really good ones. I’m running this DB on one spinning disk, so performance is very MEH. MySQL and MariaDB make some assumptions about disk performance which is used to scale some pretty important parameters for write caching. You can meaningfully improve on the defaults by testing your disk with a great linux utility called “fio”.

sudo apt install fio
fio --randrepeat=1 --ioengine=libaio --direct=1 --gtod_reduce=1 --name=test --filename=test --bs=4k --iodepth=64 --size=4G --readwrite=randrw --rwmixread=75

This will take a while and will give some very detailed information about the performance of your disk subsystem, the key parameters being average and max write IOPS. I typically create a # performance tuning section at the end of my [mysqld] section and before [embedded] and I’ll put these values in as, say: (your IOPS values will be different):

# performance tuning

innodb_io_capacity              = 170
innodb_io_capacity_max          = 286

and sudo service mariadb restart


After you’ve collected some data, there may be a list of tuning options.

sudo nano /etc/mysql/mariadb.conf.d/50-server.cnf

Mine currently look like this, but they’ll change as the database stabilizes and my usage patterns change.

# performance tuning

innodb_io_capacity              = 170
innodb_io_capacity_max          = 286

innodb_stats_on_metadata        = 0
innodb_buffer_pool_size         = 4G
innodb_log_file_size            = 512M
innodb_buffer_pool_instances    = 4
skip_name_resolve               = 1
query_cache_size                = 0
query_cache_type                = 0
query_cache_limit               = 2M
max_connections                 = 175
join_buffer_size                = 4M
tmp_table_size                  = 24M
max_heap_table_size             = 24M
innodb_buffer_pool_size         = 4G
max_allowed_packet              = 128M


sudo service mariadb restart

Note max_allowed_packet = 128M comes from this guide. I trust it, but it isn’t a mysqltuner suggestion.
